Display messages
Error! Main Document Only.-6 9480 HF SSB transceiver
Reviewing the EPROM program content
With the transceiver on, hold down the On/Off button. The display shows the
following test displays at three-second intervals. On releasing the On/Off button the
transceiver is turned off.
No. of ‘beeps’ Message displayed Meaning
0
.
.
.
:
:
.
Display lamp test—all segments
must be on and all the indicators lit.
0
This shows the Program (EPROM)
type number
(for example 90-20541-2).
0
Program (EPROM) issue number
(for example 5.10). Some indicator
lamps turn off.
0
Shows the number of channels
programmed by the factory or
agent. This can be up to 15.
0
These displays indicate some of the
options fitted to the transceiver.
d indicates that the transceiver is
inhibited from entering transmit
frequencies from the front panel.
E indicates that the transceiver is
enabled for entering transmit
frequencies from the front panel.
q
