Installation
3-2 9480 HF SSB transceiver
Mobile
The mobile installation (Figure 3.2) typically consists of a
12V DC power supply (battery) connected to the transceiver;
the antenna is connected to the transceiver with coaxial cable
and, for auto tuning antennas, with a control cable.
Installations may be either with front control transceivers or
extended control transceivers which include a separate
control head and speaker.
9480 transceiver
Microphone
12V Battery
Coaxial
control
cable
and
Front control transceiver
9480 transceiver
12V Battery
Microphone
Control head
Speaker
Extended control transceiver
Automatic tuning
whip antennas
Vehicle earth
Vehicle mounting
cradle
Figure 3.2: Typical mobile installation
