Installation
9480 HF SSB transceiver 3-9
Grounding
An adequate ground, or earth, is essential for satisfactory
operation of the transceiver.
A chassis ground or earthing position is provided on the rear
panel of the transceiver.
The control head should also be earthed.
q
Antennas
Correct installation of these two units is of prime importance
to the operation of your transceiver.
To obtain the best performance and good radiation efficiency
from your transceiver installation, it is important to consider
the physical location (distance from the transceiver) and
earthing of the antenna and tuner.
Detailed and specific installation instructions are provided
with each antenna and antenna tuner. These instructions must
be followed to gain the best possible results from your
antenna, antenna tuner and transceiver.
q
