Installation
9480 HF SSB transceiver 3-3
Mounting the transceiver
In mobile installations, the transceiver must be mounted
in a position that will not cause injury to occupants in the
event of a motor vehicle accident.
Mount the transceiver and control head in a position
that allows:
• easy access to the control panel
• a free flow of air through the rear cooling fins.
There are two types of mounting cradles that can be used
when installing your transceiver:
• code 117 mounting cradle—front entry (normally
supplied with the 9480)
• code 118 mounting cradle—top/bottom entry.
Both types of cradle (supplied with 6 metres of DC power
cable) can be used to mount the transceiver. You must
determine the mounting position to best suit your needs.
