Codan 9480 User Manual

Front and rear panel sockets
Error! Main Document Only.-6 9480 HF SSB transceiver
Antenna control—option AD
Pin No. Designation Pin No. Designation
1
Channel number Bit 3 (oc)
9
Channel number Bit 1
(oc)
2
Channel number Bit 4 (oc)
10
Channel number Bit 2
(oc)
3
Disable (ground to disable)
11
Switched +12V Motor
4
Load
12
Switched fused battery
voltage
5
+ 12V Scan
13
Switched fused battery
voltage
6
Motor phase 1 (oc)
14
Ground
7
Motor phase 2 (oc)
15
Motor phase 3 (oc)
8
Motor phase 4 (oc)
(oc) = Open Collector (Active high)
