Codan 9480 - The Transceiver and Control Head Front Panels

Overview
9480 HF SSB transceiver Error! Main Document Only.-3
The transceiver and control head front panels
The transceiver and control head front panels (refer to the figures on pages 2-8 and 2-
9) have the following control panel designations:
Item No. Item Function
1
Tx
The indicator is lit when the transceiver is
transmitting.
2
On/Off
Switches the transceiver on or off.
3
1
Disp
• Shows the options programmed for the
selected channel exhibited on the LCD.
• Is used to interrogate received selective call
memory.
• Keys in the number 1.
4
2
Dim
• Dims the display and indicators when
pressed.
• Keys in the number 2.
5
3 • Keys in the number 3.
• Is used for PIN setup.
6
4
Keys in the number 4.
7
5
Keys in the number 5.
