Using the trans
ceiver
9480 HF SSB transceiver
Error! Main D
ocument Only.
-9
Selecting channels
Using the Channel buttons
Step
Action…
Di
splay shows…
Rem
arks…
1.
Press either the up
or down
arrow
Channel
The cha
nnel number
selected appears in the
lower left hand corner of
the display, and the
transmit and receiv
e
frequenc
ies to the right.
Pressing these buttons
moves to the next higher
or lower ch
annel. Keep a
button pres
sed to move
quickly through the
channels.
q
40
42
