9480 HF SSB transceiver Error! Main Document Only.-1
11. Specifications
Frequency range Transmit: 2 to 24 MHz
Receive: 250 kHz to 30 MHz
Channel capacity 15 channels
Operating mode Single sideband (J3E; USB/LSB)
Transmitted power
output
125 watts (PEP)
Supply voltage 12V DC nominal, negative earth
Normal operating range 10.5V to 15V DC
Maximum operating range 9V to 16V DC
Reverse polarity protection is provided
Over voltage
protection
Shutdown at 16V DC (nominal) for duration of over voltage
Supply current Receive (no signal): 0.4A
Transmit J3E voice: 6A (average)
J3E two tone: 9—12A
Size and weight 9480 transceiver
250 mm W x 320 mm D x 78 mm H; 3.3 kg
(excludes vehicle mounting frame)
9482 control head
190 mm W x 50 mm D x 75 mm H; 0.4 kg
(includes mounting bracket)
