Installation
9480 HF SSB transceiver 3-5
Code 118 mounting cradle—top/bottom entry
Step Action
1.
Secure the mounting cradle into position with its spring clips
nearest the front. Ensure there is sufficient space at the rear
of the cradle to take the transceiver heat sink and connectors.
2.
Remove the front and rear fixing screws of the transceiver
side rails (the centre screw to be left untouched).
Note: Adaptor plates have to be fitted to the transceiver
side rails to secure the transceiver to the cradle.
3.
Secure the adaptor plates flush to the transceiver side rails
with the new screws provided, and fit one ‘O’ ring over each
projecting stud. The adaptor plates projecting studs fit into
the slides in the cradle.
4.
Insert the transceiver adaptor plate studs into the cradle
slides and push fully into the cradle.
5.
Secure the transceiver into the cradle with the spring clips.
