Codan NGT 2010 RF User Manual

08-05300-001
09 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Handset PCB 11-06080 1
Handset, PCB 08-05300 1
Handset 04-03125 1
Build Standard, 2020 01-01251 1
1 PCB, Handset IMP 07-01761-05 07-01761-05 1
2 Header (P) 20way 2row thin
insul
Berg 67997-120 60-00200-262 1
3 Label, Serial/Barcode Codan 06-02068 06-02068 1
C1 15p 5% 50V NPO 1206
NiSn
Philips 1206CG150J9BB- 46-11500-080 1
C2 15p 5% 50V NPO 1206
NiSn
Philips 1206CG150J9BB- 46-11500-080 1
C3 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C4 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C5 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C6 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C7 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C8 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C9 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C10 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C11 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C12 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C13 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C14 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C15 22n 10% 100V X7R 1206
NiSn
Philips 12062R223K0BB- 46-42200-280 1
C16 22n 10% 100V X7R 1206
NiSn
Philips 12062R223K0BB- 46-42200-280 1
C17 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C18 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C19 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C20 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C21 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C22 470p 5% 50V NPO 1206
NiSn
Philips 1206CG471J9BB- 46-24700-080 1
C23 470p 5% 50V NPO 1206
NiSn
Philips 1206CG471J9BB- 46-24700-080 1
C24 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C25 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
08-05300-001 - Handset PCB
BOM Revision
Date Valid On
Page 1 of 5
