Codan NGT 2010 RF - 08-03993

08-03993
10 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
MicroP & Tcvr I/F PCB Rapier Electronics 08-03993 1
MicroP & Tcvr I/F 04-02690 1
1 PCB, MicroP & Tcvr I/F Codan 07-01347 07-01347 1
2 Ejector, PCB Bottom Mtg Critchley 031177 30-09900-001 1
3 Nut, M2,5 MS Zn Pl Hex Spec 01-00201 31-22500-001 31-22500-001 2
4 Screw, M2,5x10 304 SS Pan
Pozi
* 31-22510-580 31-22510-580 2
5 Nut, M3 MS Zn Pl Hex Spec 01-00201 31-23000-001 31-23000-001 1
6 Screw, M3x6 304 SS Pan Pozi * 31-23006-580 31-23006-580 1
7 Socket, 28DIL IC L/Prof
Machined
Texas Instruments C72-28-59 60-00283-231 1
8 Socket, 68PLCC IC AMP 821574-1 60-00683-351 1
9 Stake, Terminal Autosplice 7-22461-5 61-40300-004 8
C1 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C2 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C3 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C4 1n 10% 100V PE Cap Philips 2222 370 51102 46-31000-524 1
C5 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C6 1n 10% 100V PE Cap Philips 2222 370 51102 46-31000-524 1
C7 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C8 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C9 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C10 1u 10% 63V PE Cap Philips 2222 370 11105 46-61000-521 1
C11 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C12 10u 20% 25V TA Cap AVX TAP106M025CCS 47-11002-510 1
C13 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C14 220p 10% 100V CE
Cap
Philips 2222 630 03221 46-22200-200 1
C15 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C16 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C17 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C18 2,2u 20% 35V TA Cap AVX TAP225M035CCS 47-02203-510 1
C19 220p 10% 100V CE
Cap
Philips 2222 630 03221 46-22200-200 1
C20 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C21 2,2u 20% 35V TA Cap AVX TAP225M035CCS 47-02203-510 1
08-03993 - MicroP & Tcvr I/F PCB
BOM Revision
Date Valid On
Page 1 of 5
