Codan NGT 2010 RF User Manual

08-05962-001
06 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Fundamental Xtal Osc PCB 08-05962 1
Fundamental Xtal Oscillator 04-03410 1
1 PCB, Fundamental Xtal Osc IMP 07-01980-03 07-01980-03 1
C1 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C2 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C3 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C4 22p 5% 50V NPO 0805
NiSn
Philips 0805CG220J9B200 46-12200-081 1
C5 47p 5% 50V NPO 0805
NiSn
Philips 0805CG470J9B200 46-14700-080 1
C6 15p 5% 50V NPO 0603
NiSn
Philips 0603CG150C9BB00 46-11500-083 1
C7 2 - 10p Ceramic Trim Cap
SMD
Voltronics JZ100 49-51100 1
C8 4,7p 0,25p 50V NPO 0603
NiSn
Philips 0603CG479C9B200 46-04700-084 1
C9 2,2p 0,25p 50V NPO 0603
NiSn
AVX 06035A2R2CAT2A 46-02200-082 1
C10 4,7p 0,25p 50V NPO 0603
NiSn
Philips 0603CG479C9B200 46-04700-084 1
C11 8,2p 0,25p 50V NPO 0603
NiSn
Philips 0603CG829C9BB00 46-08200-082 1
IC1 Inverter, Single Unbuffered
SOT23-5
SGS Thomson 74V1GU04S YZ-74004-700 1
IC2 Inverter, Single Unbuffered
SOT23-5
SGS Thomson 74V1GU04S YZ-74004-700 1
IC3 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
R1 1M Ohm 5% 0,06W 0603 Philips 2322 702 60105 40-61000-121 1
R2 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
08-05962-001 - Fundamental Xtal Osc PCB
BOM Revision
Date Valid On
Page 1 of 1
