Codan NGT 2010 RF User Manual

08-05926-001
04 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
TP, Hi Pwr PA & Ant Controller 10-00890 1
High Pwr Amplifier Controller 04-03377 1
Assy Proc,High Pwr PA&Ant
Cntr
11-06066 1
High Pwr PA & Ant Controller 08-05926 1
1 Junction Box Diemetrics 05-07066 05-07066 1
2 Junction Box, Base Plate Diemetrics 05-07067 05-07067 1
3 Escutcheon, Top,PA Controller Entech 06-02099 06-02099 1
4 Escutcheon,Front,PA
Controller
Entech 06-02100 06-02100 1
5 PCB, High Pwr Amp Controller IMP 07-01960-01 07-01960-01 1
6 Screw, M3x8 TAPTITE 2 Csk
Pozi
Ajax Fasteners 304SS Bk to 01-00205 31-03008-782 4
7 Standoff #4-40x7 Avdel 1115-4470 33-40504-070 4
8 Screw lock assy, 'D' 5,0mm
Stud
ACD 1-024 60-91563-001 4
9 Washer, M3 304 SS Spring W.J.Smith 31-23001-580 31-23001-580 2
C1 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C2 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C3 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C4 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C5 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C6 10n 10% 100V X7R 0805
NiSn
Philips 08052R103K0B200 46-41000-281 1
C7 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C8 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C9 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C10 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C11 22p 5% 50V NPO 0805
NiSn
Philips 0805CG220J9B200 46-12200-081 1
C12 10n 10% 100V X7R 0805
NiSn
Philips 08052R103K0B200 46-41000-281 1
C13 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C14 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C15 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C16 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C17 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C18 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
08-05926-001 - High Pwr PA & Ant Controller
BOM Revision
Date Valid On
Page 1 of 5
