Codan NGT 2010 RF User Manual

08-05855-001
05 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Build Standard, 3030 01-01249 1
User Connector PCB 11-06101 1
User Connect PCB 08-05855 1
User Connect 04-03364 1
Jig, Alignment MIC Socket
RearPanel
75-80982 75-80982 1
1 PCB, User Connect IMP 07-01943-01 07-01943-01 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 Standoff #4-40x7 Avdel 1115-4470 33-40504-070 4
C101 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C102 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C103 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C104 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C105 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C106 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C108 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C109 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C110 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C111 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C112 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C113 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C114 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C115 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C116 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C117 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C118 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C119 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C120 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C121 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C122 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C123 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C124 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C125 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
08-05855-001 - User Connect PCB, 3030
BOM Revision
Date Valid On
Page 1 of 5
