Codan NGT 2010 RF User Manual

08-03905-002
05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Dual Line Equaliser 04-02541 1
* Dual Line Equaliser PCB 08-03905 1
1 PCB, Dual Line Equaliser Codan 07-01317 07-01317 1
2 Ejector, PCB Bottom Mtg Critchley 031177 30-09900-001 1
3 Nut, M2,5 MS Zn Pl Hex Spec 01-00201 31-22500-001 31-22500-001 2
4 Screw, M2,5x10 304 SS Pan
Pozi
* 31-22510-580 31-22510-580 2
5 Nut, M3 MS Zn Pl Hex Spec 01-00201 31-23000-001 31-23000-001 1
6 Screw, M3x6 304 SS Pan Pozi * 31-23006-580 31-23006-580 1
7 Stake, Terminal Autosplice 7-22461-5 61-40300-004 9
C1 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C2 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C3 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C4 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C5 100n 20% 50V X7R CE
Cap
Vitramon VP41BY104MA 46-51000-261 1
C6 10u 20% 25V TA Cap AVX TAP106M025CCS 47-11002-510 1
C7 47u 16V Ax EL Cap Jamicon SKR470T1CE11 48-14701-651 1
C8 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C9 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C101 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C102 47p 2% 100V N150 CE
Cap
Philips 2222 680 34479 46-14700-012 1
C103 10p 2% 100V NPO CE
Cap
Philips 2222 680 10109 46-11000-011 1
C104 220p 10% 100V CE
Cap
Philips 2222 630 03221 46-22200-200 1
C105 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C106 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C107 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C108 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C109 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C110 220p 2% 100V N750 CE
Cap
Philips 2222 680 58221 46-22200-013 1
C111 220p 10% 100V CE
Cap
Philips 2222 630 03221 46-22200-200 1
C112 33n 10% 100V PE Cap Philips 2222 370 21333 46-43300-524 1
C113 1n 10% 100V PE Cap Philips 2222 370 51102 46-31000-524 1
C114 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
08-03905-002 - Dual Line Equaliser PCB
BOM Revision
Date Valid On
Page 1 of 8
