08-04644-001
05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Socket, 68PLCC IC AMP 821574-1 60-00683-351 1
Socket, 28DIL IC L/Prof
Machined
Texas Instruments C72-28-59 60-00283-231 1
Screw, M2,5x10 304 SS Pan
Pozi
* 31-22510-580 31-22510-580 2
Nut, M2,5 MS Zn Pl Hex Spec 01-00201 31-22500-001 31-22500-001 2
Ejector, PCB Bottom Mtg Critchley 031177 30-09900-001 1
PCB, Gen. Purpose I/O Codan 07-01601 07-01601 1
Gen. Purpose I/O 04-02852 1
* Gen. Purpose I/O PCB 08-04644 1
* Gen. Purpose I/O PCB 08-04644 1
C101 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C102 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C103 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C104 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C105 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C106 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C107 27p 2% 100V NPO CE
Cap
Philips 2222 680 10279 46-12700-011 1
C108 27p 2% 100V NPO CE
Cap
Philips 2222 680 10279 46-12700-011 1
C109 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C110 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C111 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C112 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C113 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C114 27p 2% 100V NPO CE
Cap
Philips 2222 680 10279 46-12700-011 1
C115 27p 2% 100V NPO CE
Cap
Philips 2222 680 10279 46-12700-011 1
C116 10u 20% 25V TA Cap AVX TAP106M025CCS 47-11002-510 1
C117 10u 20% 25V TA Cap AVX TAP106M025CCS 47-11002-510 1
C118 10u 20% 25V TA Cap AVX TAP106M025CCS 47-11002-510 1
C119 10u 20% 25V TA Cap AVX TAP106M025CCS 47-11002-510 1
C120 10u 20% 25V TA Cap AVX TAP106M025CCS 47-11002-510 1
C121 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C122 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C123 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
08-04644-001 - Opt RS PCB
BOM Revision
Date Valid On
Page 1 of 3
