Codan NGT 2010 RF User Manual

08-05317-001
15 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Build Standard, 2030 01-01250 1
Microprocessor PCB 08-05317 1
MicroP 04-03133 1
Micro Processor PCB 11-06075 1
1 PCB, MicroP IMP 07-01767-09 07-01767-09 1
2 Cable, Ribbon, Micro - Audio Auto Assemblies 08-05625-001 08-05625-001 1
3 Label, Serial/Barcode Codan 06-02068 06-02068 1
4 Header (P) 10way 2row thin
insul
Berg 67997-410H 60-00100-002 1
C1 10p 5% 50V NPO 0805
NiSn
Philips 0805CG100J9B200 46-11000-081 1
C2 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C3 10p 5% 50V NPO 0805
NiSn
Philips 0805CG100J9B200 46-11000-081 1
C4 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C5 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C6 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C7 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C8 27p 5% 50V NPO 0805
NiSn
Philips 0805CG270J9B200 46-12700-080 1
C9 27p 5% 50V NPO 0805
NiSn
Philips 0805CG270J9B200 46-12700-080 1
C10 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C11 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C12 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C13 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C14 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C15 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C16 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C17 1u 10% 16V X7R 1206
NiSn
Philips 12062R105K7BB00 46-61000-280 1
C18 1u 10% 16V X7R 1206
NiSn
Philips 12062R105K7BB00 46-61000-280 1
C19 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C20 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C21 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C22 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C23 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C24 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
08-05317-001 - MicroP PCB
BOM Revision
Date Valid On
Page 1 of 4
