Codan NGT 2010 RF User Manual

08-05976-001
01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Capacitors, 44pF +/-2% Braemac 23-40024 TO 10-00936 23-40024 1
Capacitors, 10pF +/-2% Braemac 23-40050 23-40050 1
Capacitors, 36pF +/-2% Braemac 23-40049 23-40049 1
Capacitors, 76pF +/-2% Braemac 23-40048 23-40048 1
Capacitors, 108pF +/-2% Braemac 23-40047 23-40047 1
Capacitors, 104pF +/-2% Braemac 23-40046 23-40046 1
Capacitors, 12pF +/-2% Braemac 23-40045 23-40045 1
Capacitors, 54pF +/-2% Braemac 23-40044 23-40044 1
Capacitors, 15pF +/-2% Braemac 23-40043 23-40043 1
Capacitors, 56pF +/-2% Braemac 23-40042 TO DRG 10-
00936
23-40042 1
Capacitors, 120pF +/-2% Braemac 23-40041 TO DRG 10-
00936
23-40041 1
Capacitors, 150pF +/-2% Braemac 23-40040 TO DRG 10-
00936
23-40040 1
Capacitors, 166pF +/-2% Braemac 23-40039 TO DRG 10-
00936
23-40039 1
Capacitors, 220pF +/-2% Braemac 23-40008 TO 10-00936 23-40008 1
Capacitors, 15pF +/-2% Braemac 23-40038 TO DRG 10-
00936
23-40038 1
Capacitors, 74pF +/-2% Braemac 23-40037 TO DRG 10-
00936
23-40037 1
Capacitors, 22pF +/-2% Braemac 23-40036 TO DRG 10-
00936
23-40036 1
Capacitors, 89pF +/-2% Braemac 23-40035 TO DRG 10-
00936
23-40035 1
Capacitors, 195pF +/-2% Braemac 23-40034 TO DRG 10-
00936
23-40034 1
Capacitors, 224pF +/-2% Braemac 23-40033 TO DRG 10-
00936
23-40033 1
Capacitors, 239pF +/-2% Braemac 23-40032 TO DRG 10-
00936
23-40032 1
Capacitors, 27pF +/-2% Braemac 23-40031 TO DRG 10-
00936
23-40031 1
Capacitors, 103pF +/-2% Braemac 23-40030 TO 10-00936 23-40030 1
Capacitors, 42pF +/-2% Braemac 23-40029 TO 10-00936 23-40029 1
Capacitors, 156pF +/-2% Braemac 23-40028 TO 10-00936 23-40028 1
Capacitors, 276pF +/-2% Braemac 23-40027 TO 10-00936 23-40027 1
Capacitors, 332pF +/-2% Braemac 23-40026 TO 10-00936 23-40026 1
Capacitors, 368pF +/-2% Braemac 23-40025 TO 10-00936 23-40025 1
Capacitors, 540pF +/-2% Braemac 23-40007 TO 10-00936 23-40007 1
Capacitors, 100pF +/-2% Braemac 23-40010 TO 10-00936 23-40010 1
Capacitors, 720pF +/-2% Braemac 23-40013 TO 10-00936 23-40013 1
Capacitors, 176pF +/-2% Braemac 23-40023 TO 10-00936 23-40023 1
Capacitors, 74pF +/-2% Braemac 23-40022 TO 10-00936 23-40022 1
Capacitors, 236pF +/-2% Braemac 23-40021 TO 10-00936 23-40021 1
Capacitors, 460pF +/-2% Braemac 23-40020 TO 10-00936 23-40020 1
Capacitors, 518pF +/-2% Braemac 23-40019 TO 10-00936 23-40019 1
Capacitors, 550pF +/-2% Braemac 23-40018 TO 10-00936 23-40018 1
Capacitors, 68pF +/-2% Braemac 23-40017 TO 10-00936 23-40017 1
Capacitors, 282pF +/-2% Braemac 23-40016 TO 10-00936 23-40016 1
Capacitors, 124pF +/-2% Braemac 23-40015 TO 10-100936 23-40015 1
Capacitors, 352pF +/-2% Braemac 23-40014 TO 10-00936 23-40014 1
Capacitors, 440pF +/-2% Braemac 23-40009 TO 10-00936 23-40009 1
Capacitors, 1080pF +/-2% Braemac 23-40006 TO 10-00936 23-40006 1
Capacitors, 1210pF +/-2% Codan 23-40005 TO 10-00936 23-40005 1
Capacitors, 1320pF +/-2% Braemac 23-40004 TO 10-00936 23-40004 1
08-05976-001 - 500/1000W HF Filter PCB
BOM Revision
Date Valid On
Page 1 of 4
