Codan NGT 2010 RF User Manual

08-06320-001
04 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Desk Console (Voice) 04-03514 1
Desk Console PCB (Voice) 08-06320 1
S/W mstr assy for 90-20637-
001 ver 1.00
90-30637-001 1
Label, 32 pin PLCC Codan 06-01674 06-01674 1
1 PCB, Desk Console (Voice) IMP 07-02085-02 07-02085-02 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 Stake, Terminal Autosplice 7-22461-5 61-40300-004 2
C1 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C2 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C3 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C4 1n 5% 25V NPO 0603
NiSn
AVX 06033A102JAT2A 46-31000-083 1
C5 1n 5% 25V NPO 0603
NiSn
AVX 06033A102JAT2A 46-31000-083 1
C6 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C7 1n 5% 25V NPO 0603
NiSn
AVX 06033A102JAT2A 46-31000-083 1
C8 1n 5% 25V NPO 0603
NiSn
AVX 06033A102JAT2A 46-31000-083 1
C9 1u 10% 10V X7R 0805
NiSn
Phycomp 2222-240-15663 46-61000-281 1
C10 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C11 1u 10% 10V X7R 0805
NiSn
Phycomp 2222-240-15663 46-61000-281 1
C12 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C13 22n 10% 25V X7R 0603
NiSn
AVX 06033C223KAT2A 46-42200-281 1
C14 22n 10% 25V X7R 0603
NiSn
AVX 06033C223KAT2A 46-42200-281 1
C15 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C16 1n 5% 25V NPO 0603
NiSn
AVX 06033A102JAT2A 46-31000-083 1
C17 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C18 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C19 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C20 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C21 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C22 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C23 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C25 22n 10% 25V X7R 0603
NiSn
AVX 06033C223KAT2A 46-42200-281 1
C26 22n 10% 25V X7R 0603
NiSn
AVX 06033C223KAT2A 46-42200-281 1
08-06320-001 - Desk Console PCB (Voice)
BOM Revision
Date Valid On
Page 1 of 4
