Codan NGT 2010 RF User Manual

08-05470-001
07 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Header (P) 3way 1row Molex 22-03-2031 60-00031-100 1
PTP, 2030, Audio PCB 10-50043 1
Audio PCB 11-06074 1
Audio 04-03201 1
Audio PCB 08-05470 1
Build Standard, 2030 01-01250 1
1 PCB, Audio IMP 07-01825-07 07-01825-07 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 Jumper (S) 2way Open Top Molex 15-38-1024 60-90410-001 2
C1 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C2 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C3 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C4 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C5 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C6 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C7 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C8 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C9 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C10 1000u 16V Ax EL Cap Jamicon SKR102T1CJ21 48-31001-651 1
C11 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C12 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C13 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C14 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C15 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C16 470u 16V Ax EL Cap Jamicon SKR470T1CG18 48-24701-651 1
C17 2,2n 5% 50V NPO 1206
NiSn
Philips 1206CG222J9BB- 46-32200-081 1
C18 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C19 2,2n 5% 50V NPO 1206
NiSn
Philips 1206CG222J9BB- 46-32200-081 1
C20 3,9n 5% 50V NPO 1206
NiSn
Philips 1206CG392J9BB0C 46-33900-080 1
C21 330p 5% 50V NPO 1206
NiSn
Philips 1206CG331J9BB- 46-23300-080 1
C22 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C23 4,7n 5% 50V NPO 1206
NiSn
Philips 1206CG472J9BB0C 46-34700-080 1
C24 4,7n 5% 50V NPO 1206
NiSn
Philips 1206CG472J9BB0C 46-34700-080 1
08-05470-001 - Audio PCB
BOM Revision
Date Valid On
Page 1 of 8
