08-05999-001
02 -- Production
28.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
Splitter 4 way 1kW Amp 04-03420 1
* Splitter 4 way PCB 1kW Amp 08-05999 1
1 PCB, Splitter 4 way 1kW Amp Codan 07-01998-02 07-01998-02 1
2 Tie, Cable 2,5mm W x 115mm
Long
Richco WIT 18 R 30-39100-004 1
3 Standoff, PCB 3,6x6 PEM KFE-3,6-6ET 33-53604-060 4
4 Stake, Terminal Autosplice 7-22461-5 61-40300-004 3
C1 39p 2% 100V NPO CE
Cap
Philips 2222 680 10399 46-13900-011 1
C2 22p 2% 100V NPO CE
Cap
Philips 2222 680 10229 46-12200-011 1
C3 22p 2% 100V NPO CE
Cap
Philips 2222 680 10229 46-12200-011 1
J1 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
J2 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
J3 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
J4 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
J5 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
R4 200 Ohm 5% 0,33W CF
Res
Philips 2322 211 13201 40-22000-020 1
R5 200 Ohm 5% 0,33W CF
Res
Philips 2322 211 13201 40-22000-020 1
R6 200 Ohm 5% 0,33W CF
Res
Philips 2322 211 13201 40-22000-020 1
R7 200 Ohm 5% 0,33W CF
Res
Philips 2322 211 13201 40-22000-020 1
R8 200 Ohm 5% 0,33W CF
Res
Philips 2322 211 13201 40-22000-020 1
R9 200 Ohm 5% 0,33W CF
Res
Philips 2322 211 13201 40-22000-020 1
R10 200 Ohm 5% 0,33W CF
Res
Philips 2322 211 13201 40-22000-020 1
R11 200 Ohm 5% 0,33W CF
Res
Philips 2322 211 13201 40-22000-020 1
T1 Txfr Auto 50:12,5 Ohm 1,6-
30MHz 20W
Protran 44-80300 44-80300 1
T2 Txfr Input Splitter 2 way 1,6-
30MHz
Protran 44-80298 44-80298 1
T3 Txfr Input Splitter 2 way 1,6-
30MHz
Protran 44-80298 44-80298 1
T4 Txfr Input Splitter 2 way 1,6-
30MHz
Protran 44-80298 44-80298 1
08-05999-001 - Splitter 4 way PCB 1kW Amp
BOM Revision
Date Valid On
Page 1 of 1
