Codan NGT 2010 RF User Manual

08-05979-001
05 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Control PCB 500/1000W HF
Amp
08-05979 1
Control 500/1000W Amp 04-03418 1
1 PCB, Control 500/1000W HF
Amp
Codan 07-01987-02 07-01987-02 1
2 Wire, Eq bn V105 Thin 7/0,2 Hartland HC0026 BN 66-03072-001 0.04
3 Wire, Eq rd V105 Thin 7/0,2 Hartland HC0026 RD 66-03072-002 0.04
4 Wire, Eq or V105 Thin 7/0,2 Hartland HC0026 OR 66-03072-003 0.04
C101 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C102 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C103 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C104 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C105 1n 10% 100V X7R 0805
NiSn
Philips 08052R102K0B200 46-31000-282 1
C106 1n 10% 100V X7R 0805
NiSn
Philips 08052R102K0B200 46-31000-282 1
C107 22p 5% 50V NPO 0805
NiSn
Philips 0805CG220J9B200 46-12200-081 1
C108 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C109 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C110 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C111 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C112 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C113 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C114 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C115 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C116 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C117 4,7u 20% 20V 6032 TA
Cap
AVX TAJC475M020R 47-04702-020 1
C118 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C119 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C120 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C121 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C122 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C123 10n 10% 100V X7R 0805
NiSn
Philips 08052R103K0B200 46-41000-281 1
08-05979-001 - Control PCB 500W HF Amp
BOM Revision
Date Valid On
Page 1 of 10
