Codan NGT 2010 RF User Manual

08-05266-001
13 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Audio I/F PCB 11-06072 1
PTP, RF Unit Audio PCB 10-50033 1
Audio Interface PCB 08-05266 1
Audio I/F 04-03109 1
Build Standard, 2010 01-01252 1
Sleeve, Sil Rubber 6x0,5 Any
Col
Jones Stroud 71-80605-199 71-80605-199 0.01
1 PCB, Audio I/F Entech 07-01742-06 07-01742-06 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 Tape, EPDM Rubber foam
12mmx3mm
Beirsdorf TESA 61102 30-39301-002 15
C1 470p 5% 50V NPO 1206
NiSn
Philips 1206CG471J9BB- 46-24700-080 1
C2 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C3 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C4 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C5 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C6 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C7 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C8 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C9 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C10 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C11 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C12 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C13 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C14 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C15 22u 20% 16V 5846 TA
Cap
NEC NRT226M16R 47-12201-620 1
C16 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C17 470p 5% 50V NPO 1206
NiSn
Philips 1206CG471J9BB- 46-24700-080 1
C18 470p 5% 50V NPO 1206
NiSn
Philips 1206CG471J9BB- 46-24700-080 1
C19 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C20 470p 5% 50V NPO 1206
NiSn
Philips 1206CG471J9BB- 46-24700-080 1
C21 2,2n 5% 50V NPO 1206
NiSn
Philips 1206CG222J9BB- 46-32200-081 1
C22 2,2n 5% 50V NPO 1206
NiSn
Philips 1206CG222J9BB- 46-32200-081 1
C23 3,9n 5% 50V NPO 1206
NiSn
Philips 1206CG392J9BB0C 46-33900-080 1
08-05266-001 - Audio I/F PCB
BOM Revision
Date Valid On
Page 1 of 9
