Codan NGT 2010 RF User Manual

08-05511-001
10 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Label, Serial/Barcode Codan 06-02068 06-02068 1
NGT PA Heatsink Assy 11-06036 1
TP, NGT PA Alignment 10-00816 1
PA & Filter 04-03169 1
PA Assy c/w Heatsink 08-05511 1
Build Standard, 2010 01-01252 1
Heatsink Diemetrics 05-07059 05-07059 1
Heat, Transfer Compound Gensil GENSIL 13 45gm Tube 71-31000-004 0.01
1 PCB, PA IMP 07-01799-06 07-01799-06 1
3 Cable, CIB Intertech 08-05483-001 08-05483-001 1
5 Cable, DC Intertech 08-05485-001 08-05485-001 1
6 Cable, Ant control Intertech 08-05486-001 08-05486-001 1
7 FET, RF Power, HF MRF255
Graded
Codan 23-20010 23-20010 2
9 Screw, M3x8 TAPTITE 2
P/Pozi
Ajax Fasteners 31-03008-580 31-03008-580 12
12 50 Ohm 80'C PTC
Thermistor
Philips 2322-660-91008 41-11500-660 1
13 Lug, Solder 3,5mm Cliford W Ltd G410 CODE 330 61-30200-025 4
14 Tubing, Heatshrink 4,8x0,2
Bk
3M FP-301 3/16" Black 71-80502-400 0.01
15 Spacer, Swaged Routley & W 05-05569 2
16 Stake, Terminal Autosplice 7-22461-5 61-40300-004 6
C200 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C201 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C202 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C203 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C204 22p 5% 50V NPO 1206
NiSn
Philips 1206CG220J9BB- 46-12200-080 1
C205 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C206 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C207 15p 5% 500V NPO 1206
NiSn
Philips 1206CG150GBB- 46-11500-082 1
C208 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C209 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C210 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C211 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C212 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C213 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C214 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C215 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C216 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
08-05511-001 - PA Assy c/w Heatsink
BOM Revision
Date Valid On
Page 1 of 5
