Codan NGT 2010 RF User Manual

08-05984-001
02 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Rear Panel PCB 08-05984 1
Rear Panel 04-03421 1
1 PCB,Rear Panel 07-01990-3 07-01990-03 1
2 Stake, Terminal Autosplice 7-22461-5 61-40300-004 4
3 Socket, UHF Fixed Marushin MR-588 60-11360-588 1
C1 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C2 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C3 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C4 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C5 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C6 10n 10% 100V X7R 0805
NiSn
Philips 08052R103K0B200 46-41000-281 1
C7 10n 10% 100V X7R 0805
NiSn
Philips 08052R103K0B200 46-41000-281 1
C8 1500u 25V 105'C Ra EL
Cap Low ESR
Nippon Chemicn LXJ25VB1500M16X20 48-31502-500 1
D1 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
J1 Socket, 9way D Filtered Str.
PCB w/Screw
Kycon KF85-ED-9S-KJ 60-00093-003 1
L1 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L2 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L3 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L4 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
P1 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
P2 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
P3 Plug, 7way Fixed NS 1507L w/round nut 60-00070-601 1
R1 220 Ohm 5% 0,1W 0805 Philips 2322 730 61221 40-22200-111 1
R2 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R3 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R4 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R5 10k Ohm 1% 0,1W 0805 Philips 2322 734 61003 40-41000-115 1
R6 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R7 68 Ohm 5% 0,1W 0805 Philips 2322 730 61689 40-16800-111 1
R8 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
08-05984-001 - Rear Panel PCB
BOM Revision
Date Valid On
Page 1 of 1
