Codan NGT 2010 RF User Manual

08-05977-001
03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
500W HF Amp 04-03416 1
* 500W HF Amp PCB 08-05977 1
1 PCB, 500W Amp Codan 07-01985-02 07-01985-02 1
3 Rivet, Tinned Brass Chobert
4,0dx9,5
Avdel 01143-00516 33-40340-095 2
4 Standoff, PCB 3,6x4 PEM KFE-3,6-4ET 33-53604-040 5
5 Stake, Terminal Autosplice 7-22461-5 61-40300-004 1
C1 56p 5% 500V N750 CE
Cap
Murata DD06 UJ 560J 500 46-15600-021 1
C2 68p 5% 500V N750 CE
Cap
Murata DD07 UJ 680J 500 46-16800-021 1
C3 120p 5% 500V NPO CE
Cap
Murata DD10 CH 121J 500 46-21200-020 1
C4 270p 2% 100V N750 CE
Cap
Philips 2222 680 58271 46-22700-013 1
C5 220p 2% 100V N750 CE
Cap
Philips 2222 680 58221 46-22200-013 1
C6 150p 5% 500V NPO CE
Cap
Murata DD11 CH 151J 500 46-21500-020 1
C7 150p 5% 500V NPO CE
Cap
Murata DD11 CH 151J 500 46-21500-020 1
C8 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C9 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C10 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C11 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C12 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C13 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C14 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C15 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C16 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C17 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C18 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C19 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C20 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C21 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C22 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C23 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C24 Not Fitted Codan **-00000-001 99-00000-001 1
C25 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
08-05977-001 - 500W HF Amp PCB
BOM Revision
Date Valid On
Page 1 of 4
