Codan NGT 2010 RF User Manual

03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05977-001 - 500W HF Amp PCB
BOM Revision
Date Valid On
C26 10n 20% 50V X7R CE
Cap
AVX SR175C103MAA 46-41000-261 1
C27 10u 20% 25V TA Cap AVX TAP106M025CCS 47-11002-510 1
C28 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C29 33n 10% 100V PE Cap Philips 2222 370 21333 46-43300-524 1
C30 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C101 56p 5% 500V N750 CE
Cap
Murata DD06 UJ 560J 500 46-15600-021 1
C102 68p 5% 500V N750 CE
Cap
Murata DD07 UJ 680J 500 46-16800-021 1
C103 120p 5% 500V NPO CE
Cap
Murata DD10 CH 121J 500 46-21200-020 1
C104 220p 2% 100V N750 CE
Cap
Philips 2222 680 58221 46-22200-013 1
C105 270p 2% 100V N750 CE
Cap
Philips 2222 680 58271 46-22700-013 1
C106 150p 5% 500V NPO CE
Cap
Murata DD11 CH 151J 500 46-21500-020 1
C107 150p 5% 500V NPO CE
Cap
Murata DD11 CH 151J 500 46-21500-020 1
C108 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C109 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C110 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C111 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C112 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C113 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C114 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C115 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C116 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C117 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C118 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C119 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C120 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C121 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C122 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C123 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C124 Not Fitted Codan **-00000-001 99-00000-001 1
D1 Diode, Schottky HV HP 5082-2800 5082-2800 1
Page 2 of 4
