Codan NGT 2010 RF User Manual

08-05861-001
02 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Build Standard, 3012 01-01248 1
DSP Modem 3012 04-03366 1
User Connector PCB, 3012 08-05861 1
1 PCB, User Connector, 3012 IMP C119-610 07-01946-02 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 Standoff #4-40x7 Avdel 1115-4470 33-40504-070 4
C1 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C2 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C3 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C4 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C5 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C6 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C7 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C8 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C9 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C10 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C11 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C12 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C13 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C14 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C15 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C16 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C17 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C18 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C19 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C20 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C21 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C22 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C23 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C24 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C25 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C26 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
08-05861-001 - User Connector PCB, 3012
BOM Revision
Date Valid On
Page 1 of 4
