Codan NGT 2010 RF User Manual

04 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05860-001 - DSP Modem PCB, 3012
BOM Revision
Date Valid On
R207 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R208 47 Ohm 5% 0,06W 0603 Philips 2322 702 60479 40-14700-121 1
R209 47 Ohm 5% 0,06W 0603 Philips 2322 702 60479 40-14700-121 1
R210 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R211 100 Ohm 5% 0,06W 0603 Philips 2322 702 60101 40-21000-121 1
R212 100 Ohm 5% 0,06W 0603 Philips 2322 702 60101 40-21000-121 1
R213 2,7k Ohm 5% 0,06W 0603 Philips 2322 702 60272 40-32700-121 1
R214 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R215 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R216 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R217 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R218 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R219 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R220 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R221 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R222 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R223 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R224 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R225 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
S101 Switch, Binary 16 Posn Smpl
Code SMD
Copal S-7070TB 62-61600 1
T101 Txfr, Line isolation SMD Etal P2781 43-30002 1
T102 Txfr, Line isolation SMD Etal P2781 43-30002 1
V101 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V201 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V202 Transistor, PNP Si SOT23 Philips BC858 BC858 1
Z101 Crystal, 27,648 MHz 3rd O/T
uPGrade SMD
HY-Q 27.648MHZ, QC49/SMD 65-90110 1
Page 5 of 5
