Codan NGT 2010 RF User Manual

08-05267-001
05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Desk Console 04-03110 1
Desk Console PCB 08-05267 1
Desk Console PCB 11-06079 1
1 PCB, Desk Console IMP 07-01743-04 07-01743-04 1
2 Label, Identification/Barcode Codan 06-01852 06-01852 1
3 Stake, Terminal Autosplice 7-22461-5 61-40300-004 2
C1 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C2 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C3 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C4 22n 10% 100V X7R 1206
NiSn
Philips 12062R223K0BB- 46-42200-280 1
C5 22n 10% 100V X7R 1206
NiSn
Philips 12062R223K0BB- 46-42200-280 1
C6 22n 10% 100V X7R 1206
NiSn
Philips 12062R223K0BB- 46-42200-280 1
C7 22n 10% 100V X7R 1206
NiSn
Philips 12062R223K0BB- 46-42200-280 1
C9 Not Fitted Codan **-00000-001 99-00000-001 1
C10 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C11 22n 10% 100V X7R 1206
NiSn
Philips 12062R223K0BB- 46-42200-280 1
C12 22n 10% 100V X7R 1206
NiSn
Philips 12062R223K0BB- 46-42200-280 1
C13 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C14 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C15 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C16 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C17 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C18 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C19 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
H1 Not Fitted Codan **-00000-001 99-00000-001 1
H2 Not Fitted Codan **-00000-001 99-00000-001 1
H3 Not Fitted Codan **-00000-001 99-00000-001 1
H4 Not Fitted Codan **-00000-001 99-00000-001 1
H5 Not Fitted Codan **-00000-001 99-00000-001 1
H6 Not Fitted Codan **-00000-001 99-00000-001 1
IC1 Remote 8 Bit I/O For IIC Bus
SOIC16
Philips PCF8574T YK-08574-700 1
IC2 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
L1 Not Fitted Codan **-00000-001 99-00000-001 1
L2 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L3 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P1 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
08-05267-001 - Desk Console PCB
BOM Revision
Date Valid On
Page 1 of 2
