Codan NGT 2010 RF User Manual

08-05854-001
07 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Header (P) 4way 2mm Latch
Fixed
AMP 173981-4 60-00040-352 1
Build Standard, 3030 01-01249 1
NRI Micro-Controller 04-03363 1
NRI Micro-Controller PCB 08-05854 1
1 PCB, NRI Micro-Controller IMP 07-01942-03 07-01942-03 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 NRI Vocoder PCB Codan 08-05870-001 08-05870-001 1
4 Fastener, PCB M3 PEM KFS2-M3 33-53004-001 1
5 Spacer Metalcraft 06-00025 06-00025 1
6 Screw, M3x12 304 SS Pan
Pozi
* 31-23012-580 31-23012-580 1
C101 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C102 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C103 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C104 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C105 2,2n 10% 100V X7R 0805
NiSn
Philips 08052R222K0B200 46-32200-281 1
C106 2,2n 10% 100V X7R 0805
NiSn
Philips 08052R222K0B200 46-32200-281 1
C107 3,9n 5% 50V NPO 1206
NiSn
Philips 1206CG392J9BB0C 46-33900-080 1
C108 330p 5% 50V NPO 0805
NiSn
Philips 0805CG331J9B200 46-23300-081 1
C109 4,7n 5% 50V NPO 1206
NiSn
Philips 1206CG472J9BB0C 46-34700-080 1
C110 4,7n 5% 50V NPO 1206
NiSn
Philips 1206CG472J9BB0C 46-34700-080 1
C111 220p 5% 50V NPO 0805
NiSn
Philips 0805CG221J9BB 46-22200-081 1
C112 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C113 2,2n 10% 100V X7R 0805
NiSn
Philips 08052R222K0B200 46-32200-281 1
C114 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C115 2,2n 10% 100V X7R 0805
NiSn
Philips 08052R222K0B200 46-32200-281 1
C116 3,9n 5% 50V NPO 1206
NiSn
Philips 1206CG392J9BB0C 46-33900-080 1
C117 330p 5% 50V NPO 0805
NiSn
Philips 0805CG331J9B200 46-23300-081 1
C118 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C119 4,7n 5% 50V NPO 1206
NiSn
Philips 1206CG472J9BB0C 46-34700-080 1
C120 4,7n 5% 50V NPO 1206
NiSn
Philips 1206CG472J9BB0C 46-34700-080 1
C121 220p 5% 50V NPO 0805
NiSn
Philips 0805CG221J9BB 46-22200-081 1
C122 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C123 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
08-05854-001 - NRI Micro-Controller PCB
BOM Revision
Date Valid On
Page 1 of 7

Codan NGT 2010 RF Specifications

General

Brand	Codan
Model	NGT 2010 RF
Category	Transceiver
Language	English
