Codan NGT 2010 RF User Manual

08-05973-001
03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Controller, Crystal Oven 08-05973 1
Controller, Crystal Oven 04-03414 1
1 PCB, Controller Crystal Oven IMP 07-01905-02 07-01905-02 1
C1 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C2 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
IC1 Amp, Rail to Rail I/O
SOT23-5
National Semiconduct LMC7101BIM5X XA-07101-700 1
R1 56k Ohm 5% 0,1W 0805 Philips 2322 730 61563 40-45600-111 1
R2 330k Ohm 5% 0,1W 0805 Philips 2322 730 61334 40-53300-111 1
R3 30k Ohm 5% NTC
Thermistor
Philips 2322 633 53303 41-04303-000 1
R4 51k Ohm 1% 0,1W 0805 Philips 2322 734 65103 40-45100-115 1
R5 820k Ohm 5% 0,1W 0805 Philips 2322 730 61824 40-58200-111 1
R6 5,6k Ohm 1% 0,1W 0805 Philips 2322 734 65602 40-35600-115 1
R7 2,2M Ohm 5% 0,1W 0805 Philips 2322 730 61225 40-62200-111 1
R8 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R9 3,3 Ohm 5% 0,125W 1206 Philips 2322 711 61338 40-03300-101 1
R10 3,3 Ohm 5% 0,125W 1206 Philips 2322 711 61338 40-03300-101 1
V1 Transistor, NPN Si SOT23 Philips BC848 BC848 1
08-05973-001 - Controller, Crystal Oven PCB
BOM Revision
Date Valid On
Page 1 of 1
