Codan NGT 2010 RF User Manual

08-05261-001
12 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
RF/IF PCB 08-05261 1
RF/IF 04-03106 1
TP, NGT Rcvr/Exciter 10-00815 1
RF/IF PCB 11-06071 1
Build Standard, 2010 01-01252 1
1 PCB, RF/IF Morris Productions 07-01740-07 07-01740-07 1
2 Screen, VCO1 & Mixer Metalcraft 05-06518 05-06518 1
3 Screen, VCO Metalcraft 05-07079 05-07079 1
4 Screen, DDS Metalcraft 05-07080 05-07080 1
5 Oven, Hi-Stab for HC18 Xtal Codan 08-05235-002 08-05235-002 1
6 Jumper (S) 2way Open Top Molex 15-38-1024 60-90410-001 1
8 Label, Serial/Barcode Codan 06-02068 06-02068 1
9 Filter, 45- MHz 4Pole 15 kHz
BW
KDK 45M15B 65-91115-000 2
10 Cable, Ribbon, Audio - RF Auto Assemblies 08-05489-001 08-05489-001 1
C101 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C102 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C103 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C104 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C105 820p 5% 50V NPO 1206
NiSn
Philips 1206CG821J9BB- 46-28200-080 1
C106 820p 5% 50V NPO 1206
NiSn
Philips 1206CG821J9BB- 46-28200-080 1
C107 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C108 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C109 820p 5% 50V NPO 1206
NiSn
Philips 1206CG821J9BB- 46-28200-080 1
C110 820p 5% 50V NPO 1206
NiSn
Philips 1206CG821J9BB- 46-28200-080 1
C111 10n 10% 100V X7R 1206
NiSn
Philips 12062R103K0BB- 46-41000-280 1
C112 150p 5% 50V NPO 0805
NiSn
Philips 0805CG151J9BB- 46-21500-081 1
C113 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C114 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C115 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C116 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C117 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C118 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C119 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C120 22p 5% 50V NPO 1206
NiSn
Philips 1206CG220J9BB- 46-12200-080 1
C121 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
08-05261-001 - RF/IF PCB
BOM Revision
Date Valid On
Page 1 of 21

Codan NGT 2010 RF Specifications

General

Brand	Codan
Model	NGT 2010 RF
Category	Transceiver
Language	English
