08-05910-001
09 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
PA Filter & Control 04-03542 1
Build Standard, 2010 01-01252 1
PCB, Filter & Control 08-05910 1
Assy Proc, NGT Filter 11-06069 1
1 PCB, Filter Control 07-01967-05 07-01967-05 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 Cable, Coax Intertech 08-05484-001 08-05484-001 1
4 Cable, Ribbon, PA - Filter Auto Assemblies 08-05487-001 08-05487-001 1
5 Cable, Ribbon, Filter - Audio Auto Assemblies 08-05488-001 08-05488-001 1
B1 Temp Sensor 10mV/degree C
SOT23
National Semiconduct LM50CIM3X LM50CIM3X 1
C1 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C2 120p 5% 500V NPO 1210
NiSn
Philips 1210CG121GBB- 46-21200-082 1
C3 120p 5% 500V NPO 1210
NiSn
Philips 1210CG121GBB- 46-21200-082 1
C4 39p 5% 500V NPO 1206
NiSn
Philips 1206CG390GBB- 46-13900-082 1
C5 120p 5% 500V NPO 1210
NiSn
Philips 1210CG121GBB- 46-21200-082 1
C6 120p 5% 500V NPO 1210
NiSn
Philips 1210CG121GBB- 46-21200-082 1
C7 120p 5% 500V NPO 1210
NiSn
Philips 1210CG121GBB- 46-21200-082 1
C8 100p 5% 500V NPO 1210
NiSn
Philips 1210CG101GBB- 46-21000-082 1
C9 100p 5% 500V NPO 1210
NiSn
Philips 1210CG101GBB- 46-21000-082 1
C10 270p 5% 500V NPO 1210
NiSn
Philips 1210CG271GBB- 46-22700-082 1
C11 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C12 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C13 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C14 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
C15 390p 5% 500V NPO 1210
NiSn
Philips 1210CG391GBB- 46-23900-082 1
C16 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C17 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
C18 390p 5% 500V NPO 1210
NiSn
Philips 1210CG391GBB- 46-23900-082 1
C19 390p 5% 500V NPO 1210
NiSn
Philips 1210CG391GBB- 46-23900-082 1
C21 150p 5% 500V NPO 1210
NiSn
Philips 1210CG151GBB- 46-21500-082 1
C22 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C23 390p 5% 500V NPO 1210
NiSn
Philips 1210CG391GBB- 46-23900-082 1
C24 68p 5% 500V NPO 1210
NiSn
Philips 1210CG680GBB- 46-16800-082 1
08-05910-001 - Filter & Control PCB
BOM Revision
Date Valid On
Page 1 of 12
