Codan NGT 2010 RF User Manual

08-05522-001
03 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Handset 04-03125 1
Handset Key-matrix PCB 08-05522 1
Key Pad PCB Assembly 11-06076 1
1 PCB, Keypad IMP 07-01784-04 07-01784-04 1
H101 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
H102 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
H103 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
H104 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
H105 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
H106 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
H107 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
H108 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
J2 Socket, 5way 1row 2mm
Fixed
Samtec SMM-105-01-S-S 60-00053-000 1
J3 Socket, 5way 1row 2mm
Fixed
Samtec SMM-105-01-S-S 60-00053-000 1
J4 Socket, 4way 1row 2mm
Fixed
Samtec SMM-104-01-S-S 60-00043-000 1
J5 Socket, 4way 1row 2mm
Fixed
Samtec SMM-104-01-S-S 60-00043-000 1
08-05522-001 - Handset Key-matrix PCB
BOM Revision
Date Valid On
Page 1 of 1
