NGT—Brief description (2010)
NGT Transceiver System Technical Service Manual 57
General information
The information in this section should be read in conjunction with the appropriate issue
of the block diagram for the NGT series Transceiver. See below to determine which issue
of the block diagram you should be viewing.
For transceivers with:
Codan part number of PCB assembly See...
Audio PCB (2030 Junction Box) 03-01032 Issue 2
04-03201
08-05470
Application Processor PCB (2010 RF Unit)
04-03108
08-05265
RF/IF PCB (2010 RF Unit)
04-03106
08-05261
04-03095
08-05235
PA PCB (2010 RF Unit)
04-03169
08-05415
08-05416
08-05511
Audio PCB (2030 Junction Box) 03-01032 Issue 4
04-03423
08-05986
RF/IF PCB (2010 RF Unit)
04-03378
08-05889
04-03410
04-03414
08-05963
08-05962
08-05973
PA PCB (2010 RF Unit)
04-03369 or 04-03542
08-05869 or 08-06461
08-05910
