Codan NGT 2010 RF User Manual

08-03995-001
03 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Ind, Common Mode bn/or Protran 44-80104 44-80104 2
* 4-Wire I/F PCB 08-03995 1
1 PCB, 4-Wire I/F Codan 07-01349 07-01349 1
2 Standoff, PCB M3x4 PEM KFE-M3-4ET 33-53004-040 4
3 Stake, Terminal Autosplice 7-22461-5 61-40300-004 10
C1 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C2 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C3 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C4 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
D1 Diode, Si small sig GP Codan 23-10005 23-10005 1
K1 Relay, 2C Bif 12V 720
Ohm
Matsushita DS2Y-S-DC12 64-21223-272 1
P1 Header (P) 8way 1row Molex 22-03-2081 60-00081-100 1
P2 Header (P) 8way 1row Molex 22-03-2081 60-00081-100 1
R1 620 Ohm 5% 0,33W CF
Res
Philips 2322 211 13621 40-26200-020 1
T1 Txfr Protran 44-30821 44-30821 1
T2 Txfr Protran 44-30821 44-30821 1
08-03995-001 - 4-Wire I/F PCB
BOM Revision
Date Valid On
Page 1 of 1
