Codan NGT 2010 RF User Manual

08-05988-001
07 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Audio & Interconnect PCB 08-05988 1
Audio & Interconnect 04-03425 1
1 PCB, Audio & Interconnect IMP 07-01994-03 07-01994-03 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 Tape, EPDM Rubber foam
12mmx3mm
Beirsdorf TESA 61102 30-39301-002 25
4 Sleeve, Sil Rubber 6x0,5 Any
Col
Jones Stroud 71-80605-199 71-80605-199 0.01
C1 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C2 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C3 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C4 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C5 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C6 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C7 470u 16V Ax EL Cap Jamicon SKR470T1CG18 48-24701-651 1
C8 1000u 16V Ax EL Cap Jamicon SKR102T1CJ21 48-31001-651 1
C9 100p 5% 50V NPO 0805
NiSn
Philips 0805CG101J9B200 46-21000-081 1
C10 100p 5% 50V NPO 0805
NiSn
Philips 0805CG101J9B200 46-21000-081 1
C11 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C12 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C13 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C14 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C15 100u 25V 105'C SMD EL
Cap Low ESR
Nippon Chemicn MVY25VC100MF80 48-21002-502 1
C16 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C17 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C18 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C19 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C20 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C21 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C22 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C23 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C24 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C25 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
08-05988-001 - Audio & Interconnect PCB
BOM Revision
Date Valid On
Page 1 of 9
