10 -- Production
27.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05511-001 - PA Assy c/w Heatsink
BOM Revision
Date Valid On
R257 270k Ohm 2% 0,125W 1206 Philips 2322 711 41274 40-52700-102 1
R258 4,7k Ohm 1% 0,125W 1206 Philips 2322 724 64702 40-34700-105 1
R259 4,7 Ohm 5% 0,125W 1206 Philips 2322 711 61478 40-04700-101 1
R260 10k Ohm 1% 0,125W 1206 Philips 2322-724-61003 40-41000-105 1
R261 Res, Voltage Dependent Philips 2322-592-52506 41-22506-592 1
R263 2,7k Ohm 2% 0,125W 1206 Philips 2322 712 61272 40-32700-102 1
R264 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
T200 Input Txfr Protran 44-80270 44-80270 1
T201 Pre-Driver I/P Txfr Protran 44-80271 44-80271 1
T202 Pre-Driver O/P Txfr Protran 44-80272 44-80272 1
T203 Driver O/P Txfr Protran 44-80273 44-80273 1
T204 Output Txfr Codan 44-80274 44-80274 1
V200 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V201 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V202 JFET, N Channel SOT23 Motorola MMBFJ310LT1 MMBFJ310LT1 1
V203 JFET, N Channel SOT23 Motorola MMBFJ310LT1 MMBFJ310LT1 1
V204 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V205 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V206 Transistor, PNP Si SOT89 Philips BC869 BC869 1
V207 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V208 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V209 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V210 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V211 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V212 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V213 Transistor, PNP Curr Mirror
SOT143
Philips BCV62B BCV62B 1
V214 Transistor, NPN Curr Mirror
SOT143
Philips BCV61B BCV61B 1
V217 Transistor, PNP Si SOT23 Philips BC856 BC856 1
V218 Transistor, PNP Si SOT23 Philips BC856 BC856 1
V219 Transistor, PNP Si SOT89 Philips BC869 BC869 1
V220 Transistor, NPN Si SOT23 Philips BC848 BC848 1
