Codan NGT 2010 RF User Manual

02 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05861-001 - User Connector PCB, 3012
BOM Revision
Date Valid On
C27 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C28 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C29 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C30 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C31 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C32 4,7u 20% 20V 6032 TA
Cap
AVX TAJC475M020R 47-04702-020 1
C33 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C34 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C35 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C36 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C37 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
D1 Diode, Schottky 40V 3A
SMC
Motorola MBRS340T3 MBRS340T3 1
D2 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D3 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D4 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
IC1 Conv, DC-DC 12Vin, 5Vout
SMD
C<(>&<)>D
Technologies
NTA-1205MC 78-03021 1
IC2 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC3 Tcvr, RS232 Dual +5V
SOIC16
Maxim MAX202CSE YI-00202-700 1
IC4 Tcvr, RS232 6Tx / 10Rx ESD
PROT TSSOP38
Maxim MAX3209ECUU YI-03209-700 1
L1 Ind, Common Mode 5.5A Taiyo Yuden CMO8RA20 43-80001 1
L2 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L3 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L4 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L5 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L6 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L7 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P1 Plug, 15way D Straight PCB
Fixed
ITT-Cannon DA-15P-OL2 60-00150-094 1
P2 Header (P) 4way 2mm Latch
Fixed
AMP 173981-4 60-00040-352 1
P3 Header (P) 10way 2mm Latch
Fixed
AMP 1-173981-0 60-00100-351 1
Page 2 of 4
