05 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05979-001 - Control PCB 500W HF Amp
BOM Revision
Date Valid On
C124 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C125 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C126 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C127 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C128 100p 5% 50V NPO 0805
NiSn
Philips 0805CG101J9B200 46-21000-081 1
C201 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C202 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C203 4,7u 20% 20V 6032 TA
Cap
AVX TAJC475M020R 47-04702-020 1
C204 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C205 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C206 Not Fitted Codan **-00000-001 99-00000-001 1
C207 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C208 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C209 1u 10% 16V X7R 1206
NiSn
Philips 12062R105K7BB00 46-61000-280 1
C210 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C211 4,7u 20% 20V 6032 TA
Cap
AVX TAJC475M020R 47-04702-020 1
C212 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C213 1u 10% 16V X7R 1206
NiSn
Philips 12062R105K7BB00 46-61000-280 1
C214 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C215 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C216 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C217 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C218 Not Fitted Codan **-00000-001 99-00000-001 1
C219 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C220 4,7u 20% 20V 6032 TA
Cap
AVX TAJC475M020R 47-04702-020 1
C221 Not Fitted Codan **-00000-001 99-00000-001 1
C222 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C223 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C224 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C225 4,7u 20% 20V 6032 TA
Cap
AVX TAJC475M020R 47-04702-020 1
Page 2 of 10
