Codan NGT 2010 RF User Manual

05 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05979-001 - Control PCB 500W HF Amp
BOM Revision
Date Valid On
C226 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C227 Not Fitted Codan **-00000-001 99-00000-001 1
D101 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D102 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D103 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D104 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D105 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D106 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D107 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D108 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D109 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D110 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D111 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D112 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D113 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D114 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D115 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D116 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D117 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D201 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D202 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D203 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D204 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D205 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D206 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D207 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D208 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D209 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D210 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
