Codan NGT 2010 RF User Manual

04 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-06320-001 - Desk Console PCB (Voice)
BOM Revision
Date Valid On
C27 22n 10% 25V X7R 0603
NiSn
AVX 06033C223KAT2A 46-42200-281 1
C28 22n 10% 25V X7R 0603
NiSn
AVX 06033C223KAT2A 46-42200-281 1
C29 22n 10% 25V X7R 0603
NiSn
AVX 06033C223KAT2A 46-42200-281 1
C30 22p 5% 100V NPO 0603
NiSn
Philips 0603CG220J0B200 46-12200-083 1
C31 22p 5% 100V NPO 0603
NiSn
Philips 0603CG220J0B200 46-12200-083 1
D1 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D2 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D3 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D4 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
H1 Not Fitted Codan **-00000-001 99-00000-001 1
H2 Not Fitted Codan **-00000-001 99-00000-001 1
IC1 Reg, Voltage +3,3V 150mA
LDO SOT23-5
Texas Instruments TPS76333DBVT XB-76333-700 1
IC2 Mux/Demux, Analog, Triple 2ch
SOIC16
Philips HEF4053BT-653 YH-40053-701 1
IC3 Amp, Operational Quad
SOIC14
National Semiconduct LM324M XA-00324-700 1
IC4 Tcvr, CAN bus 3,3v 1Mbps
w/stby SOIC8
Texas Instruments SN65HVD233D YI-65233-700 1
IC5 MCU, 8 Bit 16k Flash 8 MHz
TQFP44
Atmel ATMEGA16L-8AI YP-00016-910 1
L1 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L2 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L3 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L4 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
P1 Header (P) 10way 2mm Latch
Fixed
AMP 1-173981-0 60-00100-351 1
P2 Header (P) 8way 2mm Latch
Fixed
AMP 292161-8 60-00080-001 1
P3 Not Fitted Codan **-00000-001 99-00000-001 1
P4 Header (P) 10way 2row thin
insul
Berg 67997-410H 60-00100-002 1
P5 Header (P) 4way 2mm Latch
Fixed
AMP 173981-4 60-00040-352 1
R1 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R2 4,7k Ohm 5% 0,06W 0603 Philips 2322 702 60472 40-34700-121 1
R3 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R4 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R5 100k Ohm 5% 0,06W 0603 Philips 2322 702 60104 40-51000-121 1
Page 2 of 4
