Codan NGT 2010 RF User Manual

05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-04644-001 - Opt RS PCB
BOM Revision
Date Valid On
C124 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C125 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C126 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C127 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
D101 Diode, Si small sig GP Codan 23-10005 23-10005 1
D102 Diode, Si small sig GP Codan 23-10005 23-10005 1
IC101 Buffer, Hex Inverting Schmitt IC Motorola MC74HC14N YH-74014-000 1
IC102 Supervisory, Pwr&reset 4.75V
IC
Philips PCF1252-OP XD-01252-100 1
IC103 MCU, 8bit 16MHz
PLCC68
Philips PCB80C552-5-16WP YP-80552-900 1
IC104 Latch, Octal IC Motorola MC74HC573N YH-74573-000 1
IC105 EPROM prgmd, 8571 GPIO
Opt RS
Codan 90-20500-001 90-20500-001 1
IC106 RAM, CMOS 8k x 8 Bit IC Hitachi HM6264P-15 YM-06264-000 1
IC107 UART, CMOS IC Philips SCC2691AC1N24 YK-02691-000 1
IC108 Tcvr, RS232 Dual IC Maxim MAX232CPE YI-00232-000 1
P1 Connector, 64way Male 90 deg
PCB
ITT-Cannon G06D064P4BEBL 60-51100-064 1
R1 100k Ohm 20% 0,1W SIL
Com x5Res
Murata RGSD5X104M 40-85100-500 1
R101 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R102 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R103 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R104 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R105 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R106 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R108 470 Ohm 5% 0,33W CF
Res
Philips 2322 211 13471 40-24700-020 1
R109 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R110 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R111 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R112 1,5k Ohm 5% 0,33W CF
Res
Philips 2322 211 13152 40-31500-020 1
R113 1M Ohm 5% 0,33W CF
Res
Philips 2322 211 13105 40-61000-020 1
R114 1k Ohm 20% 0,1W SIL
Sep x5Res
Murata RGSD5Y102M 40-83101-500 1
R115 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
S101 Switch, DIP 8 way AMP 435166-5 62-60829-001 1
S102 Switch, DIP 8 way AMP 435166-5 62-60829-001 1
