Codan NGT 2010 RF User Manual

07 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05470-001 - Audio PCB
BOM Revision
Date Valid On
P6 Header (P) 4way 2mm Latch
Fixed
AMP 173981-4 60-00040-352 1
P7 Header (P) 8way 2mm Latch
Fixed
AMP 292161-8 60-00080-001 1
P8 Header (P) 3way 1row Molex 22-03-2031 60-00031-100 1
P9 Header (P) 16way 2row thin
insul
Berg 67997-416H 60-00160-001 1
P10 Header (P) 10way 2row thin
insul
Berg 67997-410H 60-00100-002 1
R1 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R2 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R3 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R4 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R5 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R6 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R7 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R8 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R9 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R10 270 Ohm 5% 0,125W 1206 Philips 2322 711 61271 40-22700-101 1
R11 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R12 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R13 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R14 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R15 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R16 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R17 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R18 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R19 330k Ohm 2% 0,125W 1206 Philips 2322-711-41334 40-53300-102 1
R20 47k Ohm 5% 0,125W 1206 Philips 2322 711 61473 40-44700-101 1
R21 3,3 Ohm 5% 0,125W 1206 Philips 2322 711 61338 40-03300-101 1
R22 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R23 51k Ohm 5% 0,1W 0805 Philips 2322 730 61513 40-45100-111 1
R25 51k Ohm 5% 0,1W 0805 Philips 2322 730 61513 40-45100-111 1
Page 5 of 8
