Codan NGT 2010 RF User Manual

05 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05986-001 - Audio PCB
BOM Revision
Date Valid On
H2 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
H3 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
IC1 EPLD prgmd, JB Audio 3V Codan 90-20622-001 90-20622-001 1
IC2 Pot, 50k Digital Quad
SOIC20
Xicor X9241US YN-09241-701 1
IC3 Amp, Audio Power 2x11w
SIL9P
Philips TDA1519C TDA1519C 1
IC4 Amp, Operational Dual
SOIC8
Texas Instruments TL082CD XA-00082-700 1
IC5 Amp, Operational Dual
SOIC8
Texas Instruments TL082CD XA-00082-700 1
IC6 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC7 Amp, Operational Dual
SOIC8
Texas Instruments TL082CD XA-00082-700 1
IC8 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC9 Switch, Analog Quad Fast
SOIC16
Harris DG445DY YI-00445-700 1
IC10 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC11 Amp, Operational Dual
SOIC8
Texas Instruments TL082CD XA-00082-700 1
IC12 Reg, Voltage +10V IC National Semiconduct LM2940T-10 XB-02940-402 1
IC13 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC14 Reg, Voltage +3,3V 150mA
LDO SOT23-5
Texas Instruments TPS76333DBVT XB-76333-700 1
K1 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
L1 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L2 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L3 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L4 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L5 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L6 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L7 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L8 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L9 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L10 Ind, Common Mode 5.5A Taiyo Yuden CMO8RA20 43-80001 1
P1 Header (P) 34way 2row Boxed
Fix
Thomas & Betts 609-3427 60-00340-001 1
P2 Header (P) 10way 2mm Latch
Fixed
AMP 1-173981-0 60-00100-351 1
P3 Header (P) 10way 2mm Latch
Fixed
AMP 1-173981-0 60-00100-351 1
P4 Not Fitted Codan **-00000-001 99-00000-001 1
