Codan NGT 2010 RF User Manual

13 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05266-001 - Audio I/F PCB
BOM Revision
Date Valid On
R102 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
V1 Transistor, NPN Si SOT23 Philips BFR92A BFR92A 1
V2 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V3 MOSFET, N Chan Enhance
SOT23
Philips BST82 BST82 1
V4 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V5 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V6 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V7 Diode, Zener 6,8V 5% 0,2W
SOT23
Philips BZX84C6V8 BZX84C6V8 1
V8 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V9 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V10 Transistor, PNP Si SOT23 Philips BC858 BC858 1
Z1 Osc, Xtal TTL 16,000 MHz HY-Q MIN80AS-T100PPM 65-91406-000 1
Z2 Crystal, 32,768kHz 12pF HY-Q TC38 65-90057-000 1
Page 9 of 9
