Codan NGT 2010 RF User Manual

12 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05261-001 - RF/IF PCB
BOM Revision
Date Valid On
C244 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C245 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C246 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C247 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C248 10n 10% 100V X7R 1206
NiSn
Philips 12062R103K0BB- 46-41000-280 1
C249 10n 10% 100V X7R 1206
NiSn
Philips 12062R103K0BB- 46-41000-280 1
C250 10p 5% 50V NPO 1206
NiSn
Philips 1206CG100J9BB- 46-11000-080 1
C251 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C252 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C253 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C254 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C255 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C256 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C257 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C258 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C259 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C260 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C261 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C262 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C263 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C265 Not Fitted Codan **-00000-001 99-00000-001 1
C266 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C267 Not Fitted Codan **-00000-001 99-00000-001 1
C268 Not Fitted Codan **-00000-001 99-00000-001 1
C269 Not Fitted Codan **-00000-001 99-00000-001 1
C270 Not Fitted Codan **-00000-001 99-00000-001 1
C271 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C272 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C273 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C274 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C275 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
