12 -- Production
27.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05261-001 - RF/IF PCB
BOM Revision
Date Valid On
D206 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D207 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D208 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D209 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D210 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D212 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D401 Diode, Tuner Si SOD323 Siemens BB639-E6327 BB639 1
D402 Diode, Tuner Si SOD323 Siemens BB639-E6327 BB639 1
D403 Diode, Tuner Si SOD323 Siemens BB639-E6327 BB639 1
D404 Diode, Tuner Si SOD323 Siemens BB639-E6327 BB639 1
D405 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D406 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D407 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D408 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D409 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D410 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
IC101 Mixer, High level IC Philips 23-30012 23-30012 1
IC102 Mixer, High level IC Philips 23-30012 23-30012 1
IC103 Mixer, High level IC Philips 23-30012 23-30012 1
IC201 Amp, RF/AGC
SOIC8
Motorola MC1350D XA-01350-700 1
IC202 Gate, NAND 2 Input Quad
SOIC14
Philips HEF4011BTD YG-40011-700 1
IC203 Array, Transistor
SOIC14
Motorola MC3346D XT-03346-700 1
IC204 Modulator, Balanced
SOIC14
Motorola MC1496D XA-01496-700 1
IC205 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
IC206 Diode, Ref 2,5V 2%
SOIC8
National Semiconduct LM336M-2,5 XB-00336-700 1
IC207 Array, Transistor
SOIC14
Motorola MC3346D XT-03346-700 1
IC208 Modulator, Balanced
SOIC14
Motorola MC1496D XA-01496-700 1
IC209 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
IC210 Reg, Voltage +5V 1A
TO263_3
National Semiconduct LM7805S XB-07805-701 1
IC401 Synthesiser, Freq SOIC16 Motorola MC145170D2 MC145170D1 1
Page 9 of 21
