12 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05261-001 - RF/IF PCB
BOM Revision
Date Valid On
R483 10 Ohm 5% 0,06W 0603 Philips 2322 702 60109 40-11000-121 1
R484 10 Ohm 5% 0,06W 0603 Philips 2322 702 60109 40-11000-121 1
R485 10 Ohm 5% 0,06W 0603 Philips 2322 702 60109 40-11000-121 1
R486 10 Ohm 5% 0,06W 0603 Philips 2322 702 60109 40-11000-121 1
R487 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R488 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R489 5,6k Ohm 5% 0,125W 1206 Philips 2322 711 61562 40-35600-101 1
R490 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R491 47k Ohm 5% 0,125W 1206 Philips 2322 711 61473 40-44700-101 1
R492 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R493 47k Ohm 5% 0,125W 1206 Philips 2322 711 61473 40-44700-101 1
R494 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R495 3,3k Ohm 5% 0,125W 1206 Philips 2322 711 61332 40-33300-101 1
R496 47k Ohm 5% 0,125W 1206 Philips 2322 711 61473 40-44700-101 1
R497 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R498 3,3k Ohm 5% 0,125W 1206 Philips 2322 711 61332 40-33300-101 1
R499 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R500 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R501 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
T101 Txfr, RF Amp Protran 44-80263 44-80263 1
T102 Txfr, Rx I/P Protran 44-80261 44-80261 1
T103 Ind, Mixer 1 L.O. Buffer Sumida 44-70491 44-70491 1
T104 45MHz Roofing Filter Txfr Sumida 44-70493 44-70493 1
T105 Txfr, Mixer 2 Input KoilKraft 44-70486 44-70486 1
T106 Txfr, Exciter O/P Protran 44-80260 44-80260 1
T107 Txfr, 45MHz roofing filtr Codan 44-70451 44-70451 1
T108 Txfr, 45MHz roofing filtr Codan 44-70451 44-70451 1
T201 Ind, Buffer Output KoilKraft 44-70487 44-70487 1
T202 Ind, Buffer Output KoilKraft 44-70487 44-70487 1
T401 Balun Protran 44-80262 44-80262 1
T402 Ind, Mixer 1 L.O. Buffer Sumida 44-70491 44-70491 1
V101 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
V102 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V103 JFET, Selected J310 01-01031 Avnet PST00-3289 PST00-3289 1
V104 JFET, Selected J310 01-01031 Avnet PST00-3289 PST00-3289 1
Page 19 of 21
